Dehydrator filter included in the package.

Compatible refrigerants:
HC (hydrocarbons) in flammability class A3, A2 and A2L including propane (R290) and isobutane (R600a)
HFO including A2L refrigerants such as R1234yf, R455A, R454C, R448A, R449A, R452A etc.
Commonly used HFCs, including R404A, R410A, R32, R134a, R407C and all class III, IV and V refrigerants. Recovery unit suitable for class I, division 2, group D T4 refrigerants.
Ex marking: CSANe 22ATEX1032X

The VRDDF recuperator is designed and tested in accordance with UL 121201, CSA C22.2 No. 213-17 and EN (IEC) 60079-7 standards.
The VRDDF recuperator is equipped with a certified explosion-proof relay, safety circuit to limit the ignition energy, operating temperature limitation systems, component insulation, etc., making the equipment suitable for working with refrigerants having flammability classes A2L, A2 and A3.

Characteristics:
High recovery speed with oil-free compressor
1 HP-0.75 kW DC brushless motor
Speed 3000 rpm
Dryer filter included
Self-purge function
Cooling fan
Easy-to-read backlit LCD display
Rugged construction for heavy duty

Specifications:
Power supply 220 V single phase 50 Hz
Motor 1 HP-0,75 kW
Engine speed 3,000 rpm
Max current consumption 6.5 A
Oil-less, air-cooled, double piston compressor
2-row capacitor, oversized for high recovery speeds in complete safety
Waterproof design with IP54 protection
Operating temperature: 0-40 °C
Safety valve (shut-off/automatic switch-off) at 38.5 bar
Recovery capacity (category V - R410A, R404A, R32, R507): 9.5 kg/minute in push/pull, 4.2 kg/minute liquid phase, 0.54 kg/minute vapour phase
Dimensions: 370 x 250 x 300 mm.
Weight: 11 kg

IMPORTANT: When working with HC refrigerants (highly flammable class A3), it is strongly recommended to use the HC-Air ventilation module. This safety device ensures that the work area is well ventilated and that any vapour, originating from a leak or release, is quickly dispersed.
