Designed to ensure high heat exchange capacity, this 10T 4R air-cooled condenser is ideal for commercial and industrial refrigeration systems requiring reliability and consistent performance.

The 4-row structure allows for a larger exchange surface area than standard versions, improving the overall efficiency of the refrigeration system. The 3.6 mm fin pitch promotes proper airflow and facilitates periodic maintenance.

The compact size allows for easy installation even in small spaces, making it suitable for both new installations and replacement or retrofitting existing systems.

The provision for a Ø230 mm fan ensures effective heat dissipation and stable operation over time, reducing the risk of drops in system performance.

Technical features:

- Type: Air condensing coil

- Configuration: 10T - 4R

- Thermal output: 1740 W

- Reference ΔT: 15°C

- Compatible fan: 1 x Ø230 mm

- Fin pitch: 3.6 mm

- Length: 300 mm

- Depth: 130 mm

- Height: 256 mm

- Application: commercial and industrial refrigeration

- Installation: new installations and replacements

Main applications:

-Cold storage rooms

- Refrigerated cabinets

- Refrigerated counters

- Refrigerated display cases

- Condensing units

- Commercial and industrial refrigeration systems

Advantages:

- Greater exchange surface thanks to the 4 rows

- High thermal efficiency

- Compact and versatile structure

- Easy installation even in small spaces

- Consistent performance over time

- Ideal for maintenance and replacement

Professional solution designed to ensure efficiency, reliability, and operational continuity in refrigeration systems, reducing downtime and optimizing system performance.
